Used HACO ERMS 16040 | Press Brakes

Description

Model: ERMS 1640
Sn: 81418
Capacity: 1600mm x 40 Metric Ton / 63" x 44 UST
Year: 2002
Comes with new punch clamps, punch and die.
Approx opening with tooling = 2.5"

SYNCHROMASTER machines are manufactured on standard production lines in Belgium, and are designed and tested by ROBOSOFT, the high tech subsidiary from the HACO GROUP. It is a synchro press brake with electronic leveling and depth-control and equipped with our user friendly ATS 585 CNC angle programming control.

SYNCHROMASTER PRESS BRAKES ARE STANDARD EQUIPPED :

 All steel welded interlocked construction, driven by two hydraulic cylinders, mounted to a side frame. A proven design to maximize performance and minimize maintenance.
 HACO-ROBOSOFT ATS 585 CNC CONTROL FOR:
X-AXES, AC drive, Angle programming
Price includes accurate back gauge on ball screws with two finger
blocks, manually adjustable in width and height.
Standard stroke X : 30” Height : 5”

Y1-Y2 AXES, SYNCHRO, programming by angle in degrees, with angle correction.

Programmable bending speed, top stop point, speed change over
point.

User friendly software in dialogue form, selection for inch/metric

Memory capacity of 400 steps, divided over 200 programs.

CNC controlled back gauge, ability to have back gauge retraction for Z-bending, fingers are manually adjustable in width and height.

Ability to tilt the beam (max. 2,5 degrees)

The two linear encoders are mounted on brackets to the side frame, to compensate side frame deflection.

Ram machined with clamping for NA and European style top tooling Bed machined for NA and European style bottom tooling
