<table><tbody><tr><td><i>Technical Specifications</i></td><td><i>Inches</i></td><td><i>millimeter</i></td></tr><tr><td>– Depth of the throat (gap)</td><td>12,99”</td><td>330mm</td></tr><tr><td>– Ram Stroke</td><td>9,84”</td><td>250mm</td></tr><tr><td>– Open Height (daylight opening)</td><td>19,69”</td><td>500mm</td></tr><tr><td>– Closed Height</td><td>9,84”</td><td>250mm</td></tr><tr><td>– Working Height</td><td>37,01”</td><td>940mm</td></tr><tr><td>– Width of the table</td><td>9,847”</td><td>250mm</td></tr><tr><td>– Motor power</td><td>22,5 kW</td><td>33,75 HP</td></tr><tr><td>– Maximum working pressure</td><td>310 Bar</td><td>310 Bar</td></tr><tr><td>– Voltage</td><td>575V/60Hz/3ph</td><td>575V/60Hz/3ph</td></tr><tr><td>– Fast approach speed</td><td>189”/min</td><td>80mm/sec</td></tr><tr><td>– Bending speed</td><td>16,5”/min</td><td>7mm/sec</td></tr><tr><td>– Fast return speed</td><td>189”/min</td><td>80mm/sec</td></tr><tr><td>– Total Length (approx.)</td><td>153,94”</td><td>3910mm</td></tr><tr><td>– Total Height (approx.)</td><td>120”</td><td>3100mm</td></tr><tr><td>– Total Width (approx.)</td><td>77,95”</td><td>1980mm</td></tr><tr><td>– Approx. Weight</td><td>44,092 Lb.</td><td>20 Ton</td></tr></tbody></table>
