Jonsen SGP1300 Deburring, Edge Rounding & Surface Finishing Machine
Have one to sell?
ConditionUsed
1 available
The Jonsen SGP1300 is engineered for high-efficiency deburring, edge rounding, and surface finishing of metal parts. Its robust design and advanced features make it ideal for processing components from laser cutting, stamping, punching, shearing, and waterjet cutting operations.
APPLICATIONS:
• Wide abrasive belt head (G) for general deburring, surface sanding, and finishing.
• Planetary abrasive barrel station (P) for deburring and edge rounding of parts coming off laser cutting/stamping/punching/shearing machines with sharp edges and minor-moderate burrs.
• Wide abrasive belt head (G) and planetary abrasive barrel station (P) can be used individually or together.
• Vacuum table with sticky conveyor belt to process small parts.
• Targeting on both inner and outer edge contours, holes, and slots.
• Capable of processing laser cut parts with laser film using P work station only (keeping the surface finish under the laser film)
• Capable of processing minor profiled (formed) parts using P work station only
Max. working width....... 1280 mm (50.4”)
Working thickness........ 0.1 – 50 mm (0.004”-1.97”) (Note: Processing thinner work pieces may cause premature wear of conveyor belt)
Min. working size........ 80 mm x 80 mm (3.15” x 3.15”) solid surface area
Feed speed............... 1.5-5 m/min (4.9-16 ft/min) (variable speed)
Weight................... 4500 KG (9900 lbs) (approx.)
Machine dimension........ L3450 x W2200 x H2220 mm (L136” x 87” x 87”) (approx.)
Overall dimension (including the wet type dust collector and vacuum generator):
L3488 x W4548 x H2605 mm (L137” x 179” x 103”) (approx.)
