The Jonsen SB1000-3TB is good for the following applications:
• Overall: De-slagging and edge rounding of plasma, high power laser, flame (oxy-fuel) cutting parts
• Dual de-slagging workstations: pin block type cross belt stations for heavy slag knock off/removal
• Follow up abrasive cross belt station further cleans parts and rounds edges
• Electro-magnetic conveyor bed accommodates small ferrous parts. Magnetic field can be turned on/off
Working width......... 1000mm (39.3″)
Working thickness..... 3mm – 80mm (0.118″-3.15″)
Min. working size..... 100mm x 100mm (3.94″ x 3.94″)
Full width electro magnetic conveyor
Feed speed............ 1-5 m/min (3.2-16.4 ft/min)
Dust extraction required
Weight................ Approximately 6,000 KG (13,200 lb)
Machine dimension..... Approximately L2800 x W2160 x H2100 mm (110x85x82″)
