<table><tbody><tr><td>Punching</td><td>Maximum Capacity (mm)</td><td>30×15</td></tr><tr><td></td><td>Diameter x Thickness (mm)</td><td>38×12</td></tr><tr><td></td><td>Stroke Length (mm)</td><td>55</td></tr><tr><td></td><td>Standard Throat Depth (mm)</td><td>220</td></tr><tr><td></td><td>Largest Hole (standard)</td><td>38</td></tr><tr><td></td><td>Largest Hole (optional)</td><td>110</td></tr><tr><td></td><td>Maximum Section</td><td>160</td></tr><tr><td></td><td>Working Height (mm)</td><td>940</td></tr><tr><td>SHEARING</td><td>Flat Bar – Max thickness (mm)</td><td>200×20</td></tr><tr><td></td><td>Flat Bar- Max width (mm)</td><td>300×15</td></tr><tr><td></td><td>Angle Flange Trim</td><td>80×10</td></tr><tr><td></td><td>Working Height (mm)</td><td>940</td></tr><tr><td>ANGLE CUTTING</td><td>90° cut</td><td>120×12</td></tr><tr><td></td><td>45° mitre max 45°</td><td>80×8</td></tr><tr><td></td><td>Working Height (mm)</td><td>1140</td></tr><tr><td>SECTION CUTTING</td><td>Round / Square</td><td>40/35</td></tr><tr><td></td><td>Channel / Beam</td><td>102×51</td></tr><tr><td></td><td>Tee</td><td>76×10</td></tr><tr><td>NOTCHING</td><td>Material Thickness (mm)</td><td>10</td></tr><tr><td></td><td>Width – Rectangular (mm)</td><td>42</td></tr><tr><td></td><td>Depth – Rectangular (mm)</td><td>100</td></tr><tr><td></td><td>Depth – Vee (mm)</td><td>60</td></tr><tr><td></td><td>Angle flange</td><td>100×10</td></tr><tr><td></td><td>Working Height (mm)</td><td>940</td></tr><tr><td>CORNER NOTCH</td><td>Maximum Capacity</td><td>150×4</td></tr><tr><td>TUBE NOTCH</td><td>Maximum Diameter (mm)</td><td>60</td></tr><tr><td>BENDING</td><td>Sheet Bending (max capacity)</td><td>150×5</td></tr><tr><td></td><td>Bar Bending on Notch End</td><td>150×12</td></tr><tr><td>NOTCH STATION PUNCHING</td><td>Throat Depth (mm)</td><td>110</td></tr><tr><td></td><td>Maximum Capacity</td><td>20×12</td></tr><tr><td>TECHNICAL DATA</td><td>Motor Power (Kw)</td><td>4</td></tr><tr><td></td><td>Net Weight (Kg)</td><td>1265</td></tr><tr><td></td><td>Gross Weight (Kg)</td><td>1385</td></tr><tr><td></td><td>Machine Dimensions (LxWxH, cm)</td><td>152x59x170</td></tr><tr><td></td><td>Packed dimensions (LxWxH, cm)</td><td>166x77x190</td></tr></tbody></table>
<figure class="vcex-image vcex-module" style="margin: 0px; box-sizing: border-box; padding: 0px; border: 0px; outline: 0px; font-variant-ligatures: normal; font-variant-caps: normal; font-variant-numeric: inherit; font-variant-east-asian: inherit; font-variant-alternates: inherit; font-variant-position: inherit; font-variant-emoji: inherit; font-stretch: inherit; font-size: 16px; line-height: inherit; font-family: Verdana, Geneva, sans-serif; font-optical-sizing: inherit; font-size-adjust: inherit; font-kerning: inherit; font-feature-settings: inherit; font-variation-settings: inherit; vertical-align: baseline; font-style: normal; font-weight: 400; color: rgb(66, 66, 66); letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; white-space: normal; background-color: rgb(255, 255, 255); text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;"><div class="vcex-image-inner wpex-relative wpex-inline-block" style="box-sizing: border-box; margin: 0px; padding: 0px; border: 0px; outline: 0px; font: inherit; vertical-align: baseline; display: inline-block; position: relative;"><img width="903" height="642" src="https://ferricmachinery.com/wp-content/uploads/2024/02/Screenshot-2024-02-05-164518-1.jpg" class="vcex-image-img wpex-align-middle" loading="lazy" decoding="async" srcset="https://ferricmachinery.com/wp-content/uploads/2024/02/Screenshot-2024-02-05-164518-1.jpg 903w, https://ferricmachinery.com/wp-content/uploads/2024/02/Screenshot-2024-02-05-164518-1-300x213.jpg 300w, https://ferricmachinery.com/wp-content/uploads/2024/02/Screenshot-2024-02-05-164518-1-768x546.jpg 768w" sizes="auto, (max-width: 903px) 100vw, 903px" style="box-sizing: border-box; margin: 0px; padding: 0px; border: 0px; outline: 0px; font: inherit; vertical-align: middle; max-width: 100%; height: auto; contain-intrinsic-size: 3000px 1500px;" data-image="8qmb79ktnv8j"></div></figure>
<p><a href="https://ferricmachinery.com/wp-content/uploads/2025/01/Kingsland-Compact.pdf" target="_blank" rel="noopener noreferrer"><br><!--EndFragment-->
